商品描述
| 尺寸 型号 | 额定流量 m3/h | 额定扬程 m | 额定功率 kw | 额定电压 v | 额定电流 A | 转速 r/min | 出水口径 | 电缆长度m | 整机重量 ㎏ | |
| mm | inch | |||||||||
| QYP100-4.5-2.2 | 100 | 4.5 | 2.2 | 380 | 5.7 | 2860 | 125 | 5 | 10 | 42 |
| QYP65-7-2.2 | 65 | 7 | 2.2 | 380 | 5.7 | 2860 | 102 | 4 | 10 | 46 |
| QYP25-17-2.2 | 25 | 17 | 2.2 | 380 | 5.7 | 2860 | 65 | 2.5 | 10 | 46 |
| QYP15-26-2.2 | 15 | 26 | 2.2 | 380 | 5.7 | 2860 | 65 | 2.5 | 10 | 46 |
| QYP160-4-3 | 160 | 4 | 3.0 | 380 | 7 | 2860 | 150 | 6 | 10 | 47 |
| QYP100-6-3 | 100 | 6 | 3.0 | 380 | 7 | 2860 | 125 | 5 | 10 | 52 |
| QYP65-10-3 | 65 | 10 | 3.0 | 380 | 7 | 2860 | 75 | 3 | 10 | 49 |
| QYP40-16-3 | 40 | 16 | 3.0 | 380 | 7 | 2860 | 75 | 3 | 10 | 51 |
| QYP25-26-3 | 25 | 26 | 3.0 | 380 | 7 | 2860 | 65 | 2.5 | 10 | 50 |
| QYP15-36-3 | 15 | 36 | 3.0 | 380 | 7 | 2860 | 50 | 2 | 10 | 51 |
| QYP12.5-40-3 | 12.5 | 40 | 3.0 | 380 | 7 | 2860 | 50 | 2 | 10 | 51 |
| QYP25-26-3.5 | 25 | 26 | 3.5 | 380 | 8.5 | 2860 | 65 | 2.5 | 10 | 50 |
| QYP30-30-3.5 | 30 | 30 | 3.5 | 380 | 8.5 | 2860 | 65 | 2.5 | 10 | 51 |
| QYP40-21-3.5 | 40 | 21 | 3.5 | 380 | 8.5 | 2860 | 75 | 3 | 10 | 58 |
| QYP40-25-4 | 40 | 25 | 4.0 | 380 | 9.6 | 2860 | 75 | 3 | 10 | 58 |
| QYP25-34-4 | 25 | 34 | 4.0 | 380 | 9.6 | 2860 | 65 | 2.5 | 10 | 61 |
